Mini high voltage generator circuit diagram in. In a very small space and powered by simple primary cells or rechargeable batteries the proposed circuit generates a low energy high voltage of the order of around 200 to 400 v harmless to humans of course but still able to give a quite nasty poke to anyone who touches it.
A simple high voltage generator circuit is explained here which can be used to step up any dc level to about 20 times or depending upon the transformer secondary rating.
High voltage generator circuit diagram. Here you can download the circuit diagram in pdf format. Mini high voltage generator circuit diagram. That i can connect the high voltage generator to the sockets i also included a transformer with a rectifier and a voltage regulator and the result was a relatively simple circuit with lots of diodes and capacitors.
Circuit operation as can be visualized in the shown high voltage arc generator circuit diagram it employs a standard transistor blocking oscillator configuration for generating. As shown here it operates as a low frequency oscillator making it possible to convert the batterys dc voltage into an ac voltage that can be stepped up via the transformer. A 12v lead acid battery can be used for powering the circuit.
T1 can be an eht extra high tension transformer used in television sets. If you build the version without the voltage doubler and measure the output voltage with your multimeter youll see a lower value than stated. Make an ultra simple high voltage generator.
These protection measures are used to ensure that any external metal parts will never be at a high voltage. Tip3055 must be mounted on a heat sink. It can make create a few kilovolts of static like.
As the circuit diagram shows the project is extremely simple as it contains only a single active element and then its only a fairly ordinary transistor. The power transistor drives primary of the step up transformer at 25 khz and as a result a high voltage will be induced across its secondary. But find it too compacted or difficult to buildwell this instructable is for you.
This high voltage generator was designed with the aim of testing the electrical breakdown protection used on the railways. Have you ever wanted to build a high voltage devices to make sparks like tesla coils marx generator and so on. This is a short high voltage generator circuit diagram of a high voltage generator and can be mounted in a small space and powered by rechargeable or simple batteries the circuit generates a voltage low current but a high turn on of about 200 to 400 v harmless to humans of course but is able to give a pretty nasty shock.
This is due to the fact that the waveform is a long way from being a sinewave and multimeters have trouble interpreting its rms root mean square.
