Not the starter wirethe on position should be fine be sure its switched not full time hot if you use the on position off your ignition switch you should be good to gothat way when you click on your ignition switch you can set your choke by steping on the go pedal and its setthan crank it. I need to wire an electric choke on my carburetor.

Ford Electric Choke Wiring Simple Schema In Edelbrock Diagram

This may be fine for quadrajet or dualjet carbs but the edelbrock will not function correctly unless it has 12 volts supplied to it.

Edelbrock electric choke wiring diagram. You can also find other images like images wiring diagram images parts diagram images replacement parts images electrical diagram images repair manuals images engine diagram. Mopar general discussions. Im in agreement with tim20 amp sounds like a lot for a choke circuit.

And i have seen it to be correct per the wiring diagram. They offer two basic models that fit a large number of engine sizes made by different manufacturers. Since i dont know what type of harness is being used in your application i will try to cover all of the bases here.

Edelbrock carburetor electric choke adjustment thanks for visiting our site this is images about edelbrock carburetor electric choke adjustment posted by ella brouillard in edelbrock category on may 20 2019. To accommodate cold starting requirements where additional fuel is needed edelbrock provides manual choke setups and electric choke. Edelbrock manufactures carburetors for classic cars and street performance machines.

Oct 15 2016 13. They told me that this was a common problem with gm installations because the stock choke wire does not provide a full 12 volts to the choke coil. Ignition coil alternator or ballast resistor.

In fact ive installed many edelbrock and holley carbs and never used a wire that heavy. Hooking up the electric choke on an edelbrock afb carb. Between the bulkhead and the ballast.

Wire to electric choke. Question about hooking up edelbrock carb. When the chryslers engineers added their electric choke assist onto this blue wire circuit they had already upgraded.

Both brands supply 16 gauge wire for hooking up power and ground for electric choke. Unfortunately this can be a bit confusing and also a bit lengthy. Looking for recommendations on where to connect the positive wire from the electric choke for my 1406 600 cfm edelbrock carb.

Edelbrock website recommends not connecting to. Where can i pick up a feed to do this.
